AJ65BT-D62 Mitsubishi Universal Model Redundant Power Supply Module

Name: AJ65BT-D62 Mitsubishi Universal Model Redundant Power Supply Module
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: AJ65BT-D62
Price: 210.00 USD
Availability: InStock

Nome da marca:	MITSUBISHI
Número do modelo:	AJ65BT-D62
MOQ:	1
preço:	Negotiations

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Lugar de origem:

Japão

Capacidade do programa:

8 K etapas

velocidade de processamento da operação básica (instrução do LD):

0,12 μs

Entrada:

24VDC

Saída:

12/24VDC (0,5A).

Detalhes da embalagem:

Nova caixa original

Destacar:

Mitsubishi redundant power supply module

universal power supply module with warranty

low voltage protection power module

Descrição do produto

AJ65BT-D62 Mitsubishi Universal Model Redundant Power Supply Module

The Mitsubishi AJ65BT-D62 is a high-speed counter module designed for the CC-Link network system within the MELSEC series. This module provides precise high-speed counting capabilities for industrial automation applications, supporting two independent channels for simultaneous operation. It is engineered to handle high-speed pulse inputs from encoders, sensors, and other pulse-generating devices, making it ideal for motion control, positioning systems, and speed measurement tasks in manufacturing and process automation environments.

Key Features

High-Speed Counting: Supports counting speeds up to 200k pulses per second for 1-phase inputs and 200k pulses per second for 2-phase inputs, ensuring accurate tracking of high-speed events.
Dual-Channel Operation: Features 2 independent channels that can be configured for various counting modes, including 1-phase and 2-phase inputs, providing flexibility for different application requirements.
Wide Input Compatibility: Accepts count input signals at DC 5V, 12V, and 24V levels, allowing integration with a broad range of industrial sensors and encoders.
CC-Link Network Integration: Functions as a remote device station on the CC-Link network, enabling distributed control and real-time data exchange with the master PLC.
Advanced Counting Modes: Offers multiple counting modes, including UP/DOWN preset counting and ring counter functionality, with a 24-bit signed binary counting range (0 to 16,777,215) for precise control.
Coincidence Output Function: Includes transistor outputs (open collector) for coincidence detection, with a fast response time of 0.1 ms or less, facilitating quick reaction to count matches.
Compact and Robust Design: Designed with a terminal block connection type for secure wiring in industrial environments, occupying 4 stations on the CC-Link network.

Material & Primary Applications

Material: The module is housed in a robust industrial-grade casing designed to withstand harsh environments. It features terminal blocks with M3.5 screws for secure connections and is built to resist industrial noise and interference.

Primary Applications:

Motion Control Systems: Ideal for precise position and speed control in automated machinery and robotics.
Production Line Monitoring: Used for counting products, monitoring conveyor belt speeds, and controlling sequential operations.
Test and Measurement Equipment: Suitable for applications requiring accurate pulse counting and frequency measurement.
Packaging and Material Handling: Provides high-speed counting for filling, capping, and sorting operations.

Technical Specifications

Parameter	Specification
Number of Channels	2
Counting Speed (Max)	200k pulses/second (1-phase input), 200k pulses/second (2-phase input)
Count Input Signal Level	DC 5V, 12V, 24V (2-5 mA)
Counting Range	24-bit signed binary (0 to 16,777,215)
External Input Signal	DC 5V, 12V, 24V (2-5 mA)
Coincidence Output	Transistor output (open collector), DC 12/24V, 0.5A
Response Time (Output)	≤ 0.1 ms
I/O Module Power Supply	DC 18.0 - 28.8V, 70 mA
Occupied Stations (CC-Link)	4 stations
External Connection	Terminal block type (M3.5 screws)
Dimensions (H × W × D)	65 mm × 151.9 mm × 63 mm
Weight	0.41 kg

FA-MOD PLC: Counter Module

Series	CC-LINK
Type	REMOTE HIGH-SPEED COUNTER
Power Supply (V)	24
Current Type	DC
Number of Channels	2
Int. Current Consumption (A)	0,07

Product Dimensions & Weight

Depth (mm)	65
Weight (kg)	0,41
Width (mm)	151
Height (mm)	63
